Electro-hydraulic Hybrid Press Brake
Electro-hydraulic Hybrid Press Brake
500-20000 [KN] Bending force
1500-15000 [mm] Bending length
Technical Parameters
| Main Parameters | Model | ||||||
| BDE5016 | BDE10032 | BDE10042 | BDE20060 | BDE25032 | BDE60060 | ||
| Bending Force (kN) | 500 | 1000 | 1000 | 2000 | 2500 | 6000 | |
| Bending Length (mm) | 1600 | 3200 | 4200 | 6000 | 3200 | 6000 | |
| Depth of Throat (mm) | 205 | 400 | 400 | 400 | 400 | 600 | |
| Width Between Columns (mm) | 1200 | 2600 | 3600 | 5000 | 2600 | 4800 | |
| Open Height (mm) | 460 | 480 | 480 | 480 | 500 | 670 | |
| Speed of Slide Blocks (mm/s) | Approach | 180 | 180 | 180 | 140 | 130 | 90 |
| Bend | 0-10 | 0-10 | 0-10 | 0-8 | 0-8 | 0-7 | |
| Return | 160 | 160 | 160 | 110 | 120 | 90 | |
| Overall Dimensions (L*W*H, mm) | 2100*1770*2395 | 3700*1930*2630 | 4700*1930*2630 | 6500*2150*3290 | 3700*2120*2800 | 6200*2700*4750 | |
| Machine Weight (kg) | 3400 | 6600 | 8300 | 18500 | 10300 | 52000 | |
| Main Motor Power (kw) | 5.5 | 7.5 | 7.5 | 18.5 | 18.5 | 45 | |
Competitive Strengths
⇲ Unique design
* Its machine tool bed is high in strength, of which frame is under more uniform stress after undergoing finite element analysis
* The electro-hydraulic hybrid synchronization technology helps to take more accurate control of slide blocks
* High-precision back gauge system, driven by servo motor, stands out in precision and reliability
⇲ High-standard machine tool
Keep machine tool indeformable and unbroken at high temperature even after long-time use because of going through 7 standard processes like high annealing and aging treatment
⇲ Mechanical deflection compensation system
The system mobilizes wedge blocks after control system calculating compensations required, then, plays its role against the crooked or distorted upper & lower beam, hence, difference among bending workpieces is minimal
⇲ Rich in bending processes
Bend up & down, and arc, dead-edge, U-shaped, enclosed-type bending, as well as bend in right, acute, obtuse angle and other complex shapes
⇲ Unique design
* Its machine tool bed is high in strength, of which frame is under more uniform stress after undergoing finite element analysis
* The electro-hydraulic hybrid synchronization technology helps to take more accurate control of slide blocks
* High-precision back gauge system, driven by servo motor, stands out in precision and reliability
⇲ High-standard machine tool
Keep machine tool indeformable and unbroken at high temperature even after long-time use because of going through 7 standard processes like high annealing and aging treatment
⇲ Mechanical deflection compensation system
The system mobilizes wedge blocks after control system calculating compensations required, then, plays its role against the crooked or distorted upper & lower beam, hence, difference among bending workpieces is minimal
⇲ Rich in bending processes
Bend up & down, and arc, dead-edge, U-shaped, enclosed-type bending, as well as bend in right, acute, obtuse angle and other complex shapes
⇲ Graphical programming
Users are permitted to plan and simulate bending processes graphically, so that bending speed and accuracy will be optimized
⇲ Automatic calculation
It can calculate the spread length, bending force, clamping point, deflection compensation, back gauge and other parameters automatically
⇲ Automatic measurement and compensation
Measure sheet thickness in real time, change bending parameters to compensate the thickness deviation, in order to keep bending angle accurate
⇲ Intelligent interconnection
Reserve robot/truss expansion interface for loading & unloading, so as to make bending, loading & unloading fully automatic
