Portable Handheld Pulsed Laser Cleaning Machine
Portable Handheld Pulsed Laser Cleaning Machine
0.2-0.3 [kW] Laser power
22 [㎡/h] Max cleaning speed
0.85/1.3 [kg] Weight of cleaning gun
5 [m] Max length of cleaning gun’s optical fiber
Technical Parameters
| Main Parameters | Model | |
| SF200HC | SF300HC | |
| Laser Power (kW) | 0.2 | 0.3 |
| Laser Wavelength (nm) | 1064 | 1064 |
| Max Pulse Energy (mJ) | 5 | 15 |
| Weight of Cleaning Gun (kg) | 0.85 | 1.3 |
| Length of Cleaning Gun Line (m) | 5 | 5 |
| Net Weight of Machine (kg) | 40 | 40 |
| Overall Dimensions (L*W*H, mm) | 600*275*556 | 600*275*556 |
| Machine cooling | Air-cooled | Air-cooled |
| Languages | 11 kinds of languages like Chinese, English, French | |
| Power Supply | Single-phase 220V, 50/60HZ | |
Competitive Strengths
⇲ Tried-and-tested design
* Highly integrated structure requiring less space, incl. laser generator, cleaning gun head, control unit and cooling components
* Handheld cleaning gun supports 8 kinds of cleaning modes and 10 safety alarms
* 4 universal casters below make 360° moving and outdoor work possible
⇲ Pulsed laser
The pulsed laser, just as its name implies, emits intermittent laser beam and takes accurate control of laser energy to concentrate on the contaminated layer, with less heat effect and no harm to substrate
⇲ Low costs of use
You will start your cleaning only by powering on, requiring no chemical reagents, hand grinding, nor extra consumables.
⇲ Tried-and-tested design
* Highly integrated structure requiring less space, incl. laser generator, cleaning gun head, control unit and cooling components
* Handheld cleaning gun supports 8 kinds of cleaning modes and 10 safety alarms
* 4 universal casters below make 360° moving and outdoor work possible
⇲ Pulsed laser
The pulsed laser, just as its name implies, emits intermittent laser beam and takes accurate control of laser energy to concentrate on the contaminated layer, with less heat effect and no harm to substrate
⇲ Low costs of use
You will start your cleaning only by powering on, requiring no chemical reagents, hand grinding, nor extra consumables.
⇲ Ease of operation
Take accurate control of peak power, scanning width and cleaning path for proper cleaning process
⇲ Real-time monitoring
Supervise laser generator, water chiller, etc.
⇲ 11 kinds of languages
Adapt to users from various countries and offer barrier-free communication between man and machine
⇲ Intelligent interconnection
I/O autorun interface is reserved to interconnect with welding robot by only pressing a button. In this way, cleaning becomes automatic.
